Audit Diagnostics Tecno 786 is a small bench‑top clinical chemistry analyzer designed for routine biochemistry testing in laboratory settings.
What it is
A clinical chemistry analyzer for quantitative measurement of analytes in serum, plasma, urine, etc.
Manufactured by Audit Diagnostics and positioned as a high‑quality, innovative analyzer for routine lab work.
Key features
User interface: 12.5 cm (5 inch) touch screen for operation and parameter setting.
Data display: reaction curves, QC records, and parameter settings can be viewed on screen.
Reaction volume: minimum reaction volume of 200 µl, helping reduce reagent use.
Reproducibility: designed for consistent, repeatable results (listed under features on the product page).
Specifications
Dimensions: length 460 mm, width 330 mm, height 140 mm.
Weight: 7 kg (portable bench‑top footprint).
Wavelength range: 330–800 nm, allowing a wide range of colorimetric assays.
Sample/data capacity: more than 100 test parameters, storage for 1,060 test results and 30 days of QC results.
Reagent dispensing volume: adjustable from 200 to 3,000 µl (listed as ml on the page, but used for reagent volume).
Optical and temperature system
Light source: halogen lamp, 6 V / 10 W.
Absorbance range: −0.3 to 2.5 Abs.
Temperature control: selectable at room temperature, 25 °C, 30 °C, or 37 °C.
Flow cell: 30 ml ceramic body with quartz glass window flow cell.
